1008692 Chain Stretching Mechanism for MEKA MB-S 2.0 m³
Description:
— Article: 1008692
— Product type: Left chain stretching mechanism
— Material: Low carbon, high strength structural alloy St
— Steel grade: St 37-2 / Hot rolled
— Steel density (weight): 7.85 g/cm³
— Standart: DIN 17100 / EN 10025-2 : 2004
— Hardness: 340-470 HBW according to EN ISO 6506-1
The kit includes:
— 1004186 Body 15x200x225 mm: 1pcs
— 217-S01/10-03 Bush D=20.5x26.5x15 mm: 2 pcs
— 1004189 Wheel D=150x46.23 mm: 1 pcs
— 1009250 / 217-S01/10-05 Lock plate L=20x50x5: 1 pcs
— 1010108 Bearing 6304-2R/C3: 2 pcs
— 1002727 Retaining ring DIN472-52: 2 pcs
— 1001947 Hexagonal bolt DIN 931 / M8x15: 2 pcs
— 1002544 Stud bolt for chain streching M20x170: 1 pcs
— 1002332 Hexagonal nut DIN 934 / M20: 2 pcs
— 1004049 / 217-S01/10-06 Pin D=20x120 mm: 1 pcs
Dimensions:
— Total length: 360 mm
— Overall width: 200 mm
— Overall height: 185 mm
— Total weight: 15.9 kg
