1008867 Sealing Group Opposite Reduction Gear Side for MEKA MB-S 1.0 m³
Description:
— Article: 1008867
— Product type: Sealing Group Opposite Reduction Gear Side
The kit includes:
— 1004065 Ring 130.1х140х6 mm: 1 pcs
— 1004041 Vulkollan seal cover: 1 pcs
— 1002156 Hexagonal socket bolt DIN 912 / M10x30: 8 pcs
— 1010607 Vulkollan seal 180х270х5 mm: 2 pcs
— 1009413 Inner bearing assembly: 1 pcs
— 1007868 Bearing body: 1 pcs
— 1002305 Countersunk bolt DIN 7991 / M16x60: 6 pcs
— 1002399 Spring washer DIN 127 - 17: 6 pcs
— 1002330 Hexagonal nut DIN 934 / M16: 6 pcs
— 1002795 Greaser H1 / DIN 71412 A / M10x1: 3 pcs
— 1001424 Oil seal 170x140x15 mm: 1 pcs
— 1001345 Spherical roller bearing 23026 CC/W33: 1 pcs
— 1013145 Oil seal 170x140x14 mm: 1 pcs
— 1004063 Cover: 1 pcs
— 1001949 Hexagonal bolt DIN 933 / M8x30: 4 pcs
— 1002395 Spring washer DIN 127 - 9: 4 pcs
— 1007026 Intermediate bush: 1 pcs
— 1004064 Face washer-idle side: 1 pcs
— 1002403 Spring washer DIN 127 - 25: 1 pcs
— 1002107 Hexagonal bolt DIN 933 / M24x70: 1 pcs
Dimensions:
— Length: 440 mm
— Width: 330 mm
— Height: 275 mm
— Total weight: 97.05 kg
