1009069 Discharge Chute for MEKA MB-S 0.5 m³ / MB-S 1.0 m³
Description:
— Article: 1009069
— Product type: Discharge Chute Complete Set
— Material (discharge chute): St
— Steel grade: St 37-2 / Hot rolled
— Steel density (weight): 7.85 g/cm³
— Standart: DIN 17100 / EN 10025-2 : 2004
— Hardness: 340-470 HBW according to EN ISO 6506-1
— Assembly: Welding
— Material (wear plate): St
— Steel grade: St 42-3U / Hot rolled
— Steel density (weight): 7.85 g/cm³
— Standart: DIN 17100 / EN 10025-2 : 2004
— Hardness: 340-470 HBW according to EN ISO 6506-1
— Assembly: Bolted
The kit includes:
— 1009069 Discharge chute: 1 pcs
— .-.-.-. Discharge chute wear plate 5x653x936 mm: 1 pcs
— .-.-.-. Discharge chute wear plate 5x170x688 mm: 2 pcs
— .-.-.-. Discharge chute wear plate 5x563x713 mm: 2 pcs
— .-.-.-. Countersunk bolt DIN 7991 / M10x20: 14 pcs
— .-.-.-. Spring washer DIN 127 - 11: 14 pcs
— .-.-.-. Hexagonal nut DIN 934 / M10: 14 pcs
Dimensions:
— Chute length: 990 mm
— Chute width: 1100 mm
— Total chute height: 720 mm
— Total weight: 141.8 kg
