1009333 Side Wall Wearing Plate for MEKA MB-S 0.5 m³
Description:
— Article: 1009333
— Product type: Wear Plates for 1 Side Wall
— Material: Low carbon, high strength structural alloy St
— Steel grade: St 52-3 / Hot rolled
— Steel density (weight): 7.85 g/cm³
— Standart: DIN 17100 / EN 10025-2 : 2004
— Hardness: 490-630 HBW according to EN ISO 6506-1
— Grain size: 60 ~ 80 mm
— Approximate life values:
— for concrete B25 / M350 (max.): 750 000 m³
— for concrete B60 / M800 (max.): 150 000 m³
The kit includes:
— 1009333 Side wall wear plate: 3 pcs
— 1002288 Countersunk bolt DIN 7991 / M12x35: 15 pcs
— 1002397 Spring washer DIN 127 - 13: 15 pcs
— 1002328 Hexagonal nut DIN 934 / M12: 15 pcs
Dimensions:
— Total height of one plate: 480 mm
— Total width of one plate: 960 mm
— Single plate thickness: 10 mm
— Weight of one plate: 30.66 kg х 3 pcs
— Mounting kit weight: 0.81 kg
— Total weight: 92.78 kg
Important notes:
— The price is for a set with fasteners on one side wall of the concrete mixer.
