1009939 Sealing Group Opposite Reduction Gear Side for MEKA MB-S 0.5 m³
Description:
— Article: 1009939
— Product type: Sealing Group Opposite Reduction Gear Side
The kit includes:
— 1004042 Ring 130.1х159.9х10 mm: 1 pcs
— 1003926 Vulkollan seal cover: 1 pcs
— 1002157 Hexagonal socket bolt DIN 912 / M10x50: 8 pcs
— 1009490 Vulkollan seal 158х265х5 mm: 2 pcs
— 1000416 Oil seal 155x180x15 mm: 1 pcs
— 1003925 Seal body: 1 pcs
— 1000393 Bearing body: 1 pcs
— 1002305 Countersunk bolt DIN 7991 / M16x60: 6 pcs
— 1002399 Spring washer DIN 127 - 17: 6 pcs
— 1002347 Fibered nut DIN 982 / M16: 6 pcs
— 1002668 Retaining ring DIN 471 A - 130: 1 pcs
— 1007809 Inner bearing: 1 pcs
— 1000415 Oil seal 130x155x13 mm: 1 pcs
— 1001344 Spherical roller bearing 23024 CC/W33: 1 pcs
— 1000417 Oil seal 130x160x13 mm: 1 pcs
— 1003927 Cover: 1 pcs
— 1001969 Hexagonal bolt DIN 933 / M10x25: 8 pcs
— 1002396 Spring washer DIN 127 - 11: 8 pcs
— 1021287 Intermediate bush: 1 pcs
— 1007018 Face washer-idle side: 1 pcs
— 1002403 Spring washer DIN 127 - 25: 1 pcs
— 1009395 Hexagonal bolt DIN 933 / M24x60: 1 pcs
Dimensions:
— Overall diameter: 420 mm
— Total height: 234 mm
— Total weight: 96.2 kg
