Body Wear Plate of Cast Iron Ni-Hard Complete Set for MEKA MB-S 1.0 m³
Description:
— Article: .-.-.-.
— Product type: Body Wear Plate Complete Set
— Material: Nickel-chromium wear-resistant cast iron
— Grade: Ni-Hard 4 (contains: 5-6% Ni and 8-9% Cr)
— Standard: EN 12513: 2011-05
— Brinell hardness: 550-700 Kgf/mm²
— Grain size: 100 ~ 120 mm
— Approximate life values:
— for concrete B25 / M350 (max.): 1 000 000 m³
— for concrete B60 / M800 (max.): 200 000 m³
The kit includes:
— 1000456 Body wear plate: 56 pcs
— 1000458 Body wear plate: 2 pcs
— 1002289 Countersunk bolt DIN 7991 / M12x40: 58 pcs
— 1002397 Spring washer DIN 127 - 13: 58 pcs
— 1002328 Hexagonal nut DIN 934 / M12: 58 pcs
Dimensions:
— Plate weight: 527.8 kg
— Mounting kit weight: 3.35 kg
— Total weight: 531.15 kg
