Mixer Shaft Complete Set for MEKA MB-S 0.5 m³
Description:
— Article: .-.-.-.
— Product type: Mixer Shaft Complete Set
— Execution material (shaft): Structural steel Sk45
— Steel grade: 1.1191 / DIN 17200
— Standart: EN 10083-1 / EN 10083-3
— Brinell hardness: 172 - 255 HBW
— Assembly: Welding
— Execution material (wear plate / lateral blade): Cast iron
— Grade: Ni-Hard 4 (contains: 5-6% Ni and 8-9% Cr)
— Standard: EN 12513: 2011-05
— Brinell hardness: 550-700 Kgf/mm²
— Assembly: Bolted
— Execution material (rings): Cast steel SFERO
— Steel grade: GGG50 / EN-GJS-500-7
— Standart: EN 1563-2011
— Hardness: 170-230 HBW
— Assembly: Bolted
The kit includes:
— 1018403 Mixer shaft: 1 pcs
— 1000441 Left helix wear plate: 7 pcs
— 1000442 Right helix wear plate: 7 pcs
— 1001829 Hexagonal bolt DIN 931 / M16x50: 14 pcs
— 1002362 Wide washer DIN 9021 / M16: 14 pcs
— 1002330 Hexagonal nut DIN 934 / M16: 14 pcs
— 1011935 Lock nut DIN 985 / M16: 14 pcs
— 1000443 Left lateral blade: 1 pcs
— 1000444 Right lateral blade: 1 pcs
— 1001833 Hexagonal bolt DIN 931 / M16x75: 4 pcs
— 1007811 Eccentric washer 35x60x24.5 mm: 4 pcs
— 1011935 Lock nut DIN 985 / M16: 4 pcs
— 1019967 Left clamping ring: 1 pcs
— 1019967 Right clamping ring: 1 pcs
— 1002217 Hexagonal socket bolt DIN 912 / M16x120: 4 pcs
— 1011935 Lock nut DIN 985 / M16: 4 pcs
— 1011625 Parallel Key DIN 6885-A-B / 12.8x28x110.2: 1 pcs
Dimensions:
— Shaft length: 1789.5 mm
— Overall diameter: 1120 mm
— The weight: 488.5 kg
