XCKJ10511 Maintenance Cover Safety Switch for MEKA MB-S 0.5 m³
Description:
— Article: .-.-.-.
— Product type: Maintenance Cover Safety Switch
— Type: Telemecanique limit switches XC standard
— Device short name: XCKJ10511
— Sensor design: Form A
— Body type: Fixed
— Head type: Rotary head
— Movement of operating head: Rotary
— Type of operator: Spring return roller lever
— Contact operation: Snap action
— Switch actuation: By 30° cam
— Mechanical durability: 30000000 cycles
— Shock resistance: 50 gn for 11 ms
— Vibration resistance: 25 gn (f= 10…500 Hz)
— IP degree of protection: IP66 conforming to IEC 60529
— IK degree of protection: IK07 conforming to EN 50102
— Ambient air temperature for operation: -25…70 °C
— Ambient air temperature for storage: -40…70 °C
Dimensions:
— Width: 40 mm
— Height: 77 mm
— Depth: 44 mm
— Net weight: 0.48 kg
